FTIR Gas Analyzer with 3km Detection Range IP67 Protection and 360° Monitoring for Harsh Industrial Environments
FTIR Gas Analyzer with 3km Detection Range IP67 Protection and 360° Monitoring for Harsh Industrial Environments
  • FTIR Gas Analyzer with 3km Detection Range IP67 Protection and 360° Monitoring for Harsh Industrial Environments
  • FTIR Gas Analyzer with 3km Detection Range IP67 Protection and 360° Monitoring for Harsh Industrial Environments
  • FTIR Gas Analyzer with 3km Detection Range IP67 Protection and 360° Monitoring for Harsh Industrial Environments

FTIR Gas Analyzer with 3km Detection Range IP67 Protection and 360° Monitoring for Harsh Industrial Environments

Product Details:
Place of Origin: CHINA
Brand Name: Airppb
Certification: ISO9001
Model Number: MR-ACT
Detail Information
Place of Origin:
CHINA
Brand Name:
Airppb
Certification:
ISO9001
Model Number:
MR-ACT
Operating Temperature:
-40°C To 65°C
Alarm Type:
Audible, Visual, And Vibration Alarms
Detection Method:
Remote Sensing Via Infrared Absorption
Category:
Vehicle-Mounted/Drone
Control Method:
Remote Control Via Mobile App
Ingressprotection:
IP67
Spectral Range:
8~12 μm
Monitoring Range:
360° (azimuth)
Maximum Spectral Resolution:
Better Than 2cm-1
Spectral Acquisition Rate:
20 Spectra/sec (△σ≤2 Cm-1 , Double-sided Interferogram).
Carbon Fiber Tripod Weight::
2.5kg
Dimensions:
380x 270x 500mm
Trading Information
Minimum Order Quantity:
1
Price:
$280000
Packaging Details:
Fumigation-free wooden case
Delivery Time:
5-8
Payment Terms:
D/P,T/T
Supply Ability:
100
Product Description
FTIR Gas Analyzer: Accurate Real-Time Gas Concentration Measurements for Harsh Industrial Environments
Product Overview

The MR-ACT FTIR Gas Remote Sensing Imaging Early Warning System utilizes advanced Fourier-transform infrared spectroscopy technology to enable non-contact, real-time detection and early warning of industrial toxic and harmful volatile chemicals. The hardware framework consists of precision interferometers, infrared sensing detectors, and dedicated spectral signal processing modules, capable of accurately distinguishing hundreds of gas species with a maximum effective detection distance of 3 kilometers.

This product line offers three structural configurations: drone-mounted, vehicle-fixed integrated, and explosion-proof models, designed for high-risk operation scenarios including chemical industrial zones, environmental supervision, and accident emergency disposal. Featuring advanced miniaturized lightweight structural design and consistent operational stability, the equipment provides comprehensive safety safeguards for industrial production and public environmental governance.

Core Competitive Strengths
Long-distance Detection & Large-area Coverage
  • Effective detection distance reaches 3 km and above; gas cloud tracking can be completed remotely without personnel entering dangerous zones
  • Equipped with full-area scanning function, no auxiliary light source or on-site sampling procedures required
  • Unobstructed inspection of tank tops, pipe gallery frameworks, high tower facilities and other hard-to-access monitoring areas
Ultra-high Detection Sensitivity & Instant Alarm Output
  • Detection limit for sulfur hexafluoride (SF6) reaches 30mg/m², enabling early capture of micro-scale gas leakage signals
  • System alarm triggering latency is controlled within 5 seconds
  • Alert data can be uploaded to management platform synchronously to win critical processing time for on-site disposal
Wide-spectrum Gas Identification & Customizable Database Expansion
  • Embedded proprietary gas spectrum database supporting identification of hundreds of conventional industrial toxic and harmful gases
  • Open database expansion interface for custom gas spectrum archives according to on-site monitoring demands
Diversified Deployment Forms & Full-scenario Matching
  • Drone-mounted variant: Total weight below 5kg, compatible with mainstream small industrial drones including DJI M300 and M350
  • Vehicle-mounted & fixed station variant: Weight capped at 30kg, with anti-vibration reinforced structure
  • Explosion-proof variant: Overall weight under 150kg, explosion-proof grade ExdbⅡCT6 Gb, meeting safety operation standards for flammable and explosive environments
Optimized Structural Design & Long-term Operational Stability
  • Advanced lightweight compact layout, lowering equipment transportation, installation and operation thresholds
  • Industrial standard manufacturing standards maintain stable performance under complicated harsh climate conditions
  • Supports uninterrupted long-cycle operation
Technical Specifications
Parameter Item Technical Index
Effective Detection Distance ≥3km
Detection Sensitivity (SF6) 30mg/m²
Alarm Response Latency ≤5s
Weight of Drone-mounted Unit ≤5kg
Weight of Vehicle/Fixed Unit ≤30kg
Weight of Explosion-proof Unit ≤150kg
Explosion-proof Grade ExdbⅡCT6 Gb
Detectable Gas Categories Hundreds of types, expandable on demand
Core Hardware Modules Interferometer, Infrared Detector, Spectral Signal Acquisition & Processing Circuit
Main Application Fields
  • Chemical Industrial Zone Safety Monitoring: 24-hour uninterrupted tracking of pipeline and storage tank gas leakage for early risk intervention
  • Ecological Environment Supervision & Law Enforcement: Long-distance quantification of industrial waste gas and toxic gas emission plumes
  • Chemical Substance Leakage Emergency Screening: Rapidly pinpoint leakage sources and classify gas compositions
  • Accident Emergency Support & Site Protection: Fast on-site gas spectrum analysis to delineate hazard influence ranges
  • Public Environmental Risk Prevention: Remote identification of abnormal hazardous chemical volatilization
Core Advantages of Selecting MR-ACT System
  • Cutting-edge core spectroscopy technology with independent infrared remote sensing algorithm framework
  • Multi-form deployment scheme covering aerial patrol, mobile vehicle inspection and fixed-point station monitoring
  • Stable and durable industrial performance with optimized miniaturized hardware design
  • Safe and high-efficiency monitoring mode with non-contact remote measurement and automatic intelligent alarm
  • Strong cross-industry adaptability with mass built-in gas spectrum types and expandable database function
